Product Detail

Model No.: LBJ1500

Production Capacity: 3 Set/Sets per Month meet ...

Delivery Date: 30days

Total Power: 368KW

Means of Transport: Ocean

Packing: about 17 to 20 units 40' HQ...

Brand Name: Yueshou

Port: Qingdao

The asphalt mixing plant with capacity of 120t/h
210,000-270,000USD
about 19 units container
about 30 days to delivery

Components of Asphalt Mixing Plant LBJ1500

Item	Description	Remarks
1	Cold aggregate silos and feeders Group of 4 components The silo unit capacity: 8M³ (full hopper), total capacity 32M³; Continuous dosing belt (the feeder) and driving reduction motor, group of 4 units Two units' electric vibrator	4 SETS
2	The aggregate collecting belt conveyor Dimension: 10×650 MM, length: 16M	1 SET
3	The aggregate charging belt conveyor Dimension: 10×650 MM, Length: 8 M; capacity: 160t/h	1
4	The Drying drum Dimension: Æ 1950×7730 mm, The installation angel: 4.5°, The running speed 7.3rpm, Rotation running through 4 units electric motor and cycloid reducer, The outer side wrapped 50mm rock wool thermal insulation layer with stainless steel.	1
5	Burner group for the dryer (the oil burner) It is the Chinese full-automatic control oil burner with a diesel tank (10t) and a heavy oil tank (10t). (We can provide the imported oil burner, too) The automatic control oil burner can adjust the flame avoiding the over-heat dust burning the bag of the filter	1
6	The mixing tower with supporting legs, repairing platform and ladder	1
7	Hot aggregate elevator: adopts the double-chain elevating hopper, capacity: 140t/h	1
8	The new powder bin: 23 M³; the powder elevator adopts chain-type elevating hopper, capacity: 25 T/H	1
9	The recycling powder bin: 18 M³, with screw conveyor	1
10	The screen unit of the hot aggregate: 4 grades, capacity 140t/h	1
11	Hot aggregate storage bin: 4 numbers, the total capacity 30 M³	1
12	The metering device for the hot aggregate, powder and bitumen	3 SETS
13	The mixer capacity: 1500 kg/batch	1
14	The bag filter (with filtering area of 510m²)	1
15	*The central controlling cabin (5.19M2.25M2.5M) with the advanced controlling system and controlling device (computer)*	1
16	Bitumen tank (25t) three units with the pipeline, one unit bitumen unloading tank (10t)	4 SETS
17	The bitumen pump (capacity 25 T/H)	1
18	The heat conduction oil heating system: the thermal oil heater capacity 600.000 Kcal / h	1
